Maiman Electronics SF8025, SF8075, SF8150, SF8300
3
1. Laser diode driver features
Constant current mode
Low current ripple ≤ 10uA
Current stability 0.1%
No need to adjust voltage
Soft-start
Adjustable current limit
Reverse current protection
Crowbar circuit protection
Own software
2. Applications
Supplying laser diodes in butterfly case
3. TEC controller features
Low current ripple≤2mA
Full PID controller with the ability to set
all the coefficients
Adjustable TEC output current limit
Working with sensor NTC 10kOhm
Additional NTC thermistor input
4. Controls
Potentiometers on the board
External input
Digital control by RS-232/UART/USB
1
5. Description
SF8xxx contains a laser diode driver and a temperature controller (TEC).
Laser diode driver is a non isolated low drop out (LDO) regulator with constant current
output. Driver produces high stability and low ripple current.
TEC is a non isolated DC/DC. TEC produces low current ripples. Additional features include an
adjustable TEC output current limit and full PID controller with the ability to set all the
coefficients, providing optimal temperature regulation.
SF8xxx can be controlled by analogue or digital signals and switches on the board.
SF8xxx is housed in 61 × 101.6 mm package with aluminum base plate to aid thermal
dissipation from laser diode. The laser diode mount is located on the board. Driver can be
mounted on any thermal conductive surface enough to dissipate laser diode losses.
6. Package set
Driver – 1 pcs
50 cm ribbon cable with one 8-pin connector – 1 pcs
50 cm ribbon cable with one 20-pin connector – 1 pcs
Datasheet & User Manual – 1 pcs
USB-UART converter – 1 pcs (for ZIF versions)
High thermal conductivity graphite sheet – 1 pcs (for ZIF versions)
7. Overall dimensions and weight
Weight, g (average, +/- 3g)
10-pin with Azimuth connectors
14-pin with Azimuth connectors
1
Option, USB as external adapter
