Maiman Electronics SF8025, SF8075, SF8150, SF8300
4
8. Versions
Device
LDD MAX current, mA
LD mount
LD case
SF8025-10
250
Soldering
10-pin Type 1
SF8025-ZIF10
250
Plug-in connector
10-pin Type 1
SF8025-14
250
Soldering
14-pin Type 1
SF8025-ZIF14
250
Plug-in connector
14-pin Type 1
SF8075-10
750
Soldering
10-pin Type 1
SF8075-ZIF10
750
Plug-in connector
10-pin Type 1
SF8075-14
750
Soldering
14-pin Type 1
SF8075-ZIF14
750
Plug-in connector
14-pin Type 1
SF8150-10
1500
Soldering
10-pin Type 1
SF8150-ZIF10
1500
Plug-in connector
10-pin Type 1
SF8150-14
1500
Soldering
14-pin Type 1
SF8150-ZIF14
1500
Plug-in connector
14-pin Type 1
SF8300-10
3000
Soldering
10-pin Type 1
SF8300-ZIF10
3000
Plug-in connector
10-pin Type 1
SF8300-14
3000
Soldering
14-pin Type 1
SF8300-ZIF14
3000
Plug-in connector
14-pin Type 1
9. Absolute maximum ratings
MIN
MAX
UNIT
Vin+ to Vin-
-0.3
5.5
V
Operating temperature
-40
50
°C
Analogue control pins to GND
-0.3
5.5
V
RS-232 RXD to GND
-25
25
V
RS-232 TXD to GND
-13.2
13.2
V
UART RXD to GND
-0.3
5.5
V
UART TXD to GND
-0.3
5.5
V
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to
the device. These are stress ratings only, which do not imply functional operation of the device at
these or any other conditions beyond those indicated under recommended operating conditions.
Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
10. Recommended operating conditions
MIN
MAX
UNIT
Input voltage (V
in
)
4.8
5.2
V
Operating temperature
-10
40
°C
Analogue control pins to GND
0
5
V
RS-232 RXD to GND
-12
12
V
RS-232 TXD to GND
-12
12
V
UART RXD to GND
0
5
V
UART TXD to GND
0
5
V
