Maiman Electronics SF8025, SF8075, SF8150, SF8300
5
11. Power supply requirements
The driver requires a 5V DC power supply. The power supply must be able to cover the driver
and TEC output power and losses. The power supply must provide 20W or more (it depends on the
driver version) and line regulation ± 1%. Recommended power supply: Mean Well RS-35-5.
ATTENTION! Do not use any relay between power supply and driver. When using a relay, voltage
surges may occur and driver may fail.
12. Electrical characteristics
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
OUTPUT LDD
Output voltage
0.5
3
V
Output current
SF8025
0
250
mA
SF8075
0
750
SF8150
0
1500
SF8300
0
3000
Current ripple
10
15
uA
Pulse rate
Set by RS-232 or UART
0.1
100
Hz
Pulse duration
Set by RS-232 or UART
1
5000
ms
Rise time (Soft-start time)
SF8025
400
600
700
us
SF8075
600
800
1100
SF8150
800
1000
1200
SF8300
1000
1200
1400
Fall-time (Stop time)
SF8025
1300
1700
1800
us
SF8075
700
800
1400
SF8150
400
500
600
SF8300
300
300
400
Error-triggered fall-time (Stop time)
SF8025
8
15
25
us
SF8075
8
15
25
SF8150
8
15
25
SF8300
8
15
25
OUTPUT TEC
Output voltage
0
±4
V
Output current
0
±4
A
Current ripple
2
4
mA
Temperature change range
+15
+40
°C
CONTROLS
Enable pins low threshold
1
V
Enable pins high threshold
2.3
V
Interlock pin threshold
1
V
Interlock pin pull-up resistance
10
kΩ
LDD current set pin voltage vs.
output current
SF8025
100
mA/V
SF8075
300
SF8150
600
SF8300
1200
