PR360-110-V3
Parts list
Location PartPlace ManufacturerDescription Reference Quantity
+A /1.A5 -F1 Fuse holder Staffel ST2190.2 1.00
+A /1.B1 -QS1 1.00
+A /1.B5 -G1 Power supply 1.5A. Omron S8JX-03524CD 1.00
+A /1.C3 -T1 Transformator 110V-220V 1500VA Tecnotrafo 315A41AMK 1.00
+A /1.C5 -F2 Fuse holder Staffel ST2190.2 1.00
+A /2.A2 -QF1 Circuit breaker 2P 10A BKN BKN2P10A 1.00
+A /2.C2 -U1 SmartStep control servo Omron R7D-BP04H 1.00
+A /2.C2 -U1 Servomotor power cable Omron R7A-CAB001-5SR-E 1.00
+A /2.C2 -U1 Incremental encoder cable Omron R88A-CRGB001-5CR-E 1.00
+A /2.C2 -U1 Control cable 1m. Omron R7A-CPB001-S 1.00
+A /2.C2 -U1 Power supply cable Omron R7A-CLB002-S2 1.00
+A /2.C5 -U2 SmartStep control servo Omron R7D-BP04H 1.00
+A /2.C5 -U2 Servomotor power cable Omron R7A-CAB001-5SR-E 1.00
+A /2.C5 -U2 Incremental encoder cable Omron R88A-CRGB001-5CR-E 1.00
+A /2.C5 -U2 Control cable 1m. Omron R7A-CPB001-S 1.00
+A /2.C5 -U2 Power supply cable Omron R7A-CLB002-S2 1.00
+A /3.C1 -A1 8 inputs and 6 outputs controller Omron CP1L-L14DT-D 1.00
+A /4.B4 -A2 Touch pannel Omron NV3W-MG20-V1 1.00
+C /1.D6 -S1 Emergency push-button Omron A22EM 1.00
+C /1.D6 -S1 Push-button body Omron A223200 1.00
+C /1.D6 -S1 Contact block 1NC Omron A2201 1.00
+C /2.E2 -M1 Servomotor with incremental encoder Omron R88M-G40030H-S2 1.00
+C /2.E5 -M2 Servomotor with incremental encoder Omron R88M-G40030H-S2 1.00
+C /3.B5 -B1 Inductive sensor 3 wires M8 NPN Turck NI4U-EG08-AN6X-H1341 1.00
+C /3.B5 -B1 Connector with cable Turck RKC4.4T-5/TEL 1.00
+C /3.B5 -B2 Inductive sensor 3 wires M8 NPN Turck BI2-EG08-AN6X-H1341 1.00
+C /3.B5 -B2 Connector with cable Turck RKC4.4T-5/TEL 1.00
+C /3.B6 -S2 Push-Button (green) Omron A22FG 1.00
+C /3.B6 -S2 Push-button body Omron A223200 1.00
+C /3.B6 -S2 Contact block 1NO Omron A2210 1.00
+C /3.B6 -S2 Push-button sealing cap Omron A22Z-3600F 1.00
