Make Mendel RapidBot Mega - Page 7

MAKE MENDEL Page 7
M2.5 Details
1
M2.5 Philips
Countersink Belts &
nuts(10)
Heated Print Bed (10)
2
M2.5x20 philips
Countersink
screw(4)
X & Y mechanical switch
3
M2.5x25
Countersink
screw(2)
Z mechanical switch
aliment
M3 Details
1
M3 Nylock(43)
LMG Rail (26)
Idler Excle (1)
Flange Bearing (8)
Flange Nut (8)
2
M3x8 Philips
Countersink (4)
Extruder base Plate (4)
3
M3 X 12 Socket Cap
(21)
Motor (X,Y,Z) (17)
SMPS(4)
4
M3x15 Socket Cap
(35)
LMG Rail (22) fitting
item
Extruder Motor (3)
5
M3 X 20 Socket Cap
(21)
Flange Nut (8)
LNG Rail Fitting (4)
623 Ugra Bearing (1)
Flange Bearing (8)
6
M3 x 25 Socket
Counter Sink Cap (4)
Print Bed (4)
7
M3 Nut (8)
LMG (2 at each end)
fitting (8)
8
M3 Washer (90)
LMG Rail (26)
Flange Bearing (16)
X-Y-Z Motor (16)
SMPS (4)
Flange Nut(16)
Extruder Motor Plate (8)
M4 Details
1
M4 Nylock Nut (40
Smooth Rod Cap (8)
Acrylic Side Fitting (26)
Bed Adjustment (2)
