Quick Operation Guide
Connect the smart smoke purifier
Use pipe clamps to
hold the exhaust pipes:
09
10
1
2
3
4
1.Connect the purifier with the 2m-exhaust
pipe and lay the pipe to the window.
Tips: You can also visit the website below to
get the video tutorials.
2.Connect the Laserbox and purifier with
the 1.5m-exhaust pipe.
3.Connect the Laserbox and purifier with
the aviation connector.
4.Connect the power supply.
https://www.makeblock.com/maker-tools/laserbox-video
