M4*22x4
M4螺母x4
Beam0824-080x1
Beam0808-072x1
Building steps
M4*22x4
M4螺母x4
Beam0824-080x1
Beam0808-072x1
4*8*3垫片x4
Beam0808-072 ×1
Beam0824-080 ×1
Nut M4 ×4
Screw M4*22 ×4
Beam0808-072 ×1
Beam0824-080
×1
Nut M4 ×4
Screw M4*22 ×4
Spacer4*7*3 ×4
Note:
If your mBot is in version v1.0 (without plastic protective case), please refer to
this diagram for installation.
1
Note:
Some parts in this building example come from mBot, so you need to disassemble mBot first.
