Me RGB LED
The colored Me RGB LED module includes four RGB LEDs with adjustable full color
gamut. For each LED, its color is determined by the value of red (R), green (G) and blue
(B), and the LED itself is characterized by highlight and adjustable brightness, realizing
flowing water, flashing, rainbow light and other effects. The module interface is in
yellow, indicating single digital interface control is adopted, and it must be connected
to the yellow interface on the mainboard.
Technical specification:
Operating voltage: 5V DC
Number of light: 4 x RGB LED
Maximum current: 60mA for each, totally 240mA
Light model: WS2812-4
Brightness range: 0~255
Control method: single digital interface
Operating temperature: -25～+80°C
Angle of visibility: >140°
Module size: 52 x 24 x 18 mm (L x W x H)
