Assembled diagram
Wiring diagram
19
Note:
When you use a lithium battery to power mBot, you need to remove the lithium battery
from the battery shell and fix it to the back of mBot with Velcro, so as to ensure the
center of mBot’s gravity moves backwards.
Left wheel (left motor)
Me ultrasonic sensor
Me sound sensor
Me sound sensor
Me RGB LED
Left motor
Right motor
Please follow page 20 for programming
