Assembly
4
Chassis
Motor R
M3 nut
Screw M3×25
×1
×1
×2
×2
Motor L
M3 nut
Screw M3×25
×1
×2
×2
Wheel
×2
Screw M2.2×9
×2
×2
×1
×1
Screw M4×8
Roller Ball
Me Line Follower
×2
×1
Screw M4×8
Me Ultrasonic Sensor
×4
Brass Stud M4×25
×2
RJ25 Cable
8
7
5
6
4
3
1
2
