Makeblock Starter Robot Kit User Manual

Parts List
Pictures for reference only
6× Nylon Stud M4×30
6× Plastic Ring 4×7×2mm
2× Shaft Collar 4mm
4× Flange Bearing 4×8×3mm
1× Hex Screwdriver
1× Cross Screwdriver
2× Hex Allen Key 1.5mm
1× Wrench
20× Screw M4×8
12×
Screw M4×14
12× Nut M4
1× Nut M8
4× Headless Set Screw M3×5
4× Screw M3×8
1× Beam 0824-96
1× Beam 0824-128
2× Beam 0824-144
1× Bracket 3×3
1× Plate 3×6
1× Bracket P3
1× Caster Wheel
2×
2× DC Motor-25
1× Makeblock Orion
1× Me Ultrasonic Sensor
1× Micro USB cable
1× 6P6C RJ25 Cable-20cm
1× 6P6C RJ25 Cable-35cm
2×
2×
2×
Terminal Block
Motor Cable
Ferrite Ring
2× BaseBracket
1× Battery Holder for (6) AA
2× DC Motor-25 Bracket
2× Shaft Connector 4mm
4× Timing Pulley 90T
2× Tire 68.5×22mm
36× Track
36× Track Axle
Threaded Shaft 4×39mm
Hex Allen Key 2.5mm
1×
4× Screw M4×22
1× Me Infrared Receiver Sensor
1× Me IR Remote Controller
Hex Screwdriver
Hex Allen Key 2.5mm
Screw M4×8
Screw M4×14
Screw M4×22
Screw M3×8
Terminal Block
Headless Set Screw M3×5
Wrench
Nut M4
Hex Allen Key 1.5mmCross Screwdriver
Tool Tips
2
1
