Makita 9558HN Technical Information

Circuit diagram
P 5/ 8
Red
Clear
Color index of lead wires' sheath
Black
Brush holder A
Brush holder A
Noise suppressor*
Earth terminal (Ground terminal)
on the lead wire of Noise suppressor
Power supply
cord
Brush holder B
Brush holder B
Field
Switch
*Some countries do not use noise suppressor

Makita 9558HN Specifications

General

Input power	840 W
Cable length	2.5 m
Power source	AC
Spindle thread	M14
Idle speed (max)	11000 RPM
Grinding disc diameter	125 mm
Product color	Black, Green, Silver

Weight and Dimensions

Width	139 mm
Height	106 mm
Length	271 mm
Weight	2100 g
