Makita 9565CLR User Manual

6
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
Intended use
ENE048-1
The tool is intended for grinding, sanding and cutting of
metal and stone materials without the use of water.
Power supply
ENF002-2
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.
General Power Tool Safety
Warnings
GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
GRINDER SAFETY WARNINGS
GEB033-8
Safety Warnings Common for Grinding, Sanding, Wire
Brushing, or Abrasive Cutting-Off Operations:
1. This power tool is intended to function as a
grinder, sander, wire brush or cut-off tool. Read all
safety warnings, instructions, illustrations and
specifications provided with this power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
2. Operations such as polishing are not
recommended to be performed with this power
tool. Operations for which the power tool was not
designed may create a hazard and cause personal
injury.
3. Do not use accessories which are not specifically
designed and recommended by the tool
manufacturer. Just because the accessory can be
attached to your power tool, it does not assure safe
operation.
4. The rated speed of the accessory must be at least
equal to the maximum speed marked on the power
tool. Accessories running faster than their rated
speed can break and fly apart.
5. The outside diameter and the thickness of your
accessory must be within the capacity rating of
your power tool. Incorrectly sized accessories
cannot be adequately guarded or controlled.
6. Threaded mounting of accessories must match
the grinder spindle thread. For accessories
mounted by flanges, the arbour hole of the
accessory must fit the locating diameter of the
flange. Accessories that do not match the mounting
hardware of the power tool will run out of balance,
vibrate excessively and may cause loss of control.
1. Shaft lock
2. Slide switch
3. Indication lamp (speed adjusting
dial)
4. Speed adjusting dial
5. Abrasive disc
6. Pad
7. Spindle
8. Head cover
9. Gear housing
10. Screw
11. Wheel guard
12. Bearing box
13. Lock nut
14. Depressed center grinding wheel/
Multi-disc
15. Inner flange
16. Lock nut wrench
17. Rubber pad
18. Marking A
19. Marking B
20. Marking C
21. Pin
22. Vent
23. Wire cup brush/Wire bevel brush
24. Abrasive cut-off wheel/diamond
wheel
25. Wheel guard for abrasive cut-off
wheel/diamond wheel
26. Abrasive cut-off wheel
27. Diamond wheel
28. Thickness: Less than 4 mm
(5/32”)
29. Thickness: 4 mm (5/32”) or more
30. Exhaust vent
31. Inhalation vent
Model 9565CLR
Abrasive disc 125 mm
Max. wheel thickness 6.4 mm
Spindle thread M14
Rated speed (n) / No load speed (
n
0
) 7,800 min
-1
Overall length 311 mm
Net weight 2.1 kg
Safety class /II
