ASSEMBLY

WARNING: Always be sure that the lock key

and battery cartridge are removed before carrying

out any work on the mower. Failure to remove the

lockkeyandthebatterycartridgemayresultinseri-

ouspersonalinjuryfromaccidentalstart-up.

WARNING: Never start the mower unless it is

completely assembled. Operation of the tools in a

partiallyassembledstatemayresultinseriousper-

sonalinjuryfromaccidentalstart-up.

Installing the handle

NOTICE: When installing handles, position the

cords so that they are not caught by anything

between the handles. If the cord is damaged, the

mower switch may not work.

1. Attach the lower handle so that the holes in the

handletintheprotrusionsonthemowerbody.Insert

the bolts from inside, then attach washer A from outside,

and then tighten the thumb nuts.

►1. Lower handle 2. Washer A 3. Thumb nut

4. Protrusion 5. Hole 6. Bolt

2. Align the hole in the lower handle with the hole

in the upper handle, then insert the bolts from inside,

then attach washer B from outside, and then tighten the

thumb nuts.

►1. Upper handle 2. Hole 3. Washer B 4. Thumb nut

5. Lower handle 6. Bolt

CAUTION: Hold the upper handle rmly so

that it does not drop off your hand. Otherwise, the

handlemayfallandcauseaninjury.

3. Attach holder A and holder B to the handle.

Positionthecordsasshowninthegure.

►1. Cord 2. Holder A 3. Holder B

NOTE: When attaching holder A, be sure to x the

cord with the holder as shown in the gure.
