Makita DSP600 User Manual

20 ENGLISH
Cancelling tool registration for the
vacuum cleaner
Perform the following procedure when cancelling the
tool registration for the vacuum cleaner.
1. Install the batteries to the vacuum cleaner and the
tool.
2. Set the stand-by switch on the vacuum cleaner to
"AUTO".
1
►1. Stand-by switch
3. Press the wireless activation button on the vac-
uumcleanerfor6seconds.Thewirelessactivation
lampblinksingreenandthenbecomered.Afterthat,
press the wireless activation button on the tool in the
same way.
1 2
1 2
►1. Wireless activation button 2. Wireless activation
lamp
If the cancellation is performed successfully, the wire-
less activation lamps will light up in red for 2 seconds
and start blinking in blue.
NOTE:Thewirelessactivationlampsnishblinkingin
red after 20 seconds elapsed. Press the wireless acti-
vation button on the tool while the wireless activation
lamp on the cleaner is blinking. If the wireless acti-
vation lamp does not blink in red, push the wireless
activationbuttonbrieyandholditdownagain.

Makita DSP600 Specifications

General

Blade Diameter	165 mm
Max Cutting Capacity at 45°	40 mm
No Load Speed	2, 500 - 6, 300 RPM
Voltage	18V
Power Source	Battery
Max Cutting Capacity at 0°	56 mm
Max Cutting Capacity at 48°	38 mm
Bevel Capacity	48°
