EA3200S EA3201S EA3202S EA3203S
Stroke volume cm
3
32
Bore mm 38
Stroke mm 28.2
Max. power at speed kW / 1/min 1.35 / 10,000
Max. torque at speed Nm / 1/min 1.6 / 7,000
Idling speed / max. engine speed with bar and chain 1/min 2,800 / 12,800
Clutch engagement speed 1/min 4,100
Sound pressure level at the workplace L
pA, eq
per ISO 22868
1) 2)
dB (A) 102.6 / K
pA
= 2.5
Sound power level L
WA, Fl+Ra
per ISO 22868
1) 2)
dB (A) 111.5 / K
WA
= 2.5
Vibration acceleration a
hv, eq
per ISO 22867
1) 2)
‑ Tubular handle m/s
2
4.8 / K = 2.0
‑ Rear handle m/s
2
4.8 / K = 2.0
Carburetor Type Membranecarburetor
Ignition system Type electronic
Spark plug Type NGK CMR7A‑5
or spark plug Type ‑‑
Electrode gap mm 0.5
Fuel consumption at max. load per ISO 7293 kg/h 0.68
Specic consumption at max. load per ISO 7293 g/kWh 500
Fuel tank capacity l 0.40
Chain oil tank capacity I 0.28
Mixture ratio (fuel/two‑stroke oil)
‑ when using MAKITA oil 50 : 1
‑ when using Aspen Alkylat (two‑stroke fuel) 50 : 1 (2%)
‑ when using other oils 50 : 1 (quality grade: JASO FC or ISO EGD)
Chain brake engages manually or in case of kickback
Chain speed (at max. power) m/s 18.9
Sprocket pitch inch 3/8
Number of teeth Z 6
Chain type see the Extract from the spare‑parts list
Pitch / gauge inch / (mm) 3/8 / 0.050 (1.3) / 3/8 / 0.043 (1.1)
Guide bar, length of a cut cm 30, 35, 40
Guide‑bar type see the Extract from the spare‑parts list
Weight (fuel tank empty, without chain, guide bar and accessories) kg 4.1 4.2 4.0 4.1
1)
Figures derived in equal part from idling, full‑load and racing speed.
2)
Uncertainty (K=).
Technical data
Packing
Your MAKITA chain saw comes delivered in a protective cardboard box to protect against shipping damage.
Cardboard is a basic raw material and is consequently reuseable or suitable for recycling (waste paper recycling).
