Reparaturanleitung PS-4600 / PS-5000 6
Repair manual DCS3500 / DCS3501 / DCS4300 / DCS4301 / EA3500F / EA3501F / EA4300F / EA4301F / MEA3500L / MEA3500M / MEA4300G / MEA4300L
6 Piston ring tensioner
Piston ring band and
assembly tool for cylinders (944.600.001)
7 Assembly and disassembly wrench
Wrench for disassembling and
assembling the centrifugal
clutch (944.500.590)
8 Pressure gauge
Pressure guage for checking
the carburetor fuel valve (956.004.000)
9 Tachometer
Electronic tachometer for measuring
the engine speed of
2- and 4-stroke engines (950.233.220)
10 3/8” socket
Installation/removal of
Spark plug, clutch (944.500.864)
11 Needle-nose pliers
Various assembly/
Disassembly tasks (944.603.400)
12 Disassembly hook
Removal/installation
Brake band spring (950.237.000)
13 Over/underpressure pump
For checking sealing of
radial rings and gaskets (957.004.001)
