9
Packing
Your MAKITA chain saw comes delivered in a protective cardboard box to protect against shipping damage.
Cardboard is a basic raw material and is consequently reuseable or suitable for recycling (waste paper recycling).
Stroke volume cm
3
35
Bore mm 38
Stroke mm 30,6
Max. power at speed kW / 1/min 1,7 / 10.000
Max. torque at speed Nm / 1/min 2,0 / 7.000
Idling speed / max. engine speed with bar and chain 1/min 2.800 / 13.100
Clutch engagement speed 1/min 4.100
Sound pressure level at the workplace L
pA, eq
per ISO 22868
1) 3)
dB(A) 101,8 / K
pA
= 2,5
Sound power level L
WA, Fl + Ra
per ISO 22868
2) 3)
dB(A) 111,8 / K
WA
= 2,5
Vibration acceleration a
hv, eq
per ISO 22867
1) 3)
- Tubular handle m/s
2
4,9 / K = 2,0
- Rear handle m/s
2
5,0 / K = 2,0
Carburetor Type Membranecarburetor
Ignition system Type electronic
Spark plug Type NGK CMR6A
or spark plug Type --
Electrode gap mm 0,6
Fuel consumption at max. load per ISO 7293 kg/h 0,68
SpeciÞ c consumption at max. load per ISO 7293 g/kWh 500
Fuel tank capacity l 0,40
Chain oil tank capacity I 0,29
Mixture ratio (fuel/two-stroke oil)
- when using DOLMAR oil 50 : 1 / 100: 1 (HP-100)
- when using Aspen Alkylat (two-stroke fuel) 50 : 1 (2%)
- when using other oils 50 : 1 (quality grade: JASO FC or ISO EGD)
Chain brake engages manually or in case of kickback
Chain speed (at racing speed) m/s 25
Sprocket pitch inch 3/8
Number of teeth Z 6
Chain type see the Extract from the spare-parts list
Pitch / gauge inch / (mm) 3/8 / 0,050 (1,3) / 3/8 / 0,043 (1,1)
Guide bar, length of a cut cm 30, 35, 40
Guide-bar type see the Extract from the spare-parts list
Weight (fuel tank empty, without chain, guide bar and accessories) kg 4,4 4,5 4,4 4,5
1)
Figures derived in equal part from idling, full-load and racing speed.
2)
Figures derived in equal part from full-load and racing speed.
3)
Uncertainty (K=).
Technical data
PS-35 C PS-35 C TLC PS-35 PS-35 TLC
