(For Canada) NOTE: This spark ignition system complies with the Canadian standard ICES-002.
Technical data
Model
EM2600U EM2600L
U handle Loop handle
Dimensions: length x width x height (without cutting blade)
1,770 x 610 x 410 mm
(69-3/4 x 24 x 16-1/8”)
1,770 x 330 x 185mm
(69-3/4 x 13 x 7-1/4”)
Net Weight 5 kg (11 lbs) 5 kg (11 lbs)
Engine displacement
25.7 cm
3
(1.57 cu. in.)
Maximum engine performance 0.83 kW
Maximum rotational frequency of the spindle 8,800/min
Cutting attachment
Single piece metal blade φ230 mm (9”)
String trimmer head φ430 mm (17”)
Idling speed 3,000/min
Clutch engagement speed 4,100/min
Gear ratio 14/19
Fuel
Mixed gas
Gasoline: Two-stroke Engine Oil = 50:1
Volume (fuel tank) 0.6 L (36.6 cu. in.)
Carburetor WALBRO WYC
Spark plug NGK BPMR7A
Electrode gap 0.6 - 0.7 mm (0.024 - 0.028”)
