Makita ER2600L Original Instruction Manual

7
TECHNICAL DATA
Model ER2600L
Handle type Loop handle
Dimensions: length x width x height (without cutting tool) mm 1,645 x 220 x 510
Net weight kg 4.3
Engine type Air cooled, 2-stroke, single cylinder
Engine displacement cm
3
25.7
Maximum engine performance kW 0.83
Maximum rotational frequency of the spindle min
-1
10,000
Cutting diameter with nylon cutting head mm φ 400
Idling speed /min 3,000
Clutch engagement speed /min 4,100
Fuel
Mixed gas
Gasoline: Two-stroke Engine Oil = 50:1
Volume (fuel tank) L 0.6
Carburetor WALBRO WYC
Spark plug NGK BPMR7A
Electrode gap mm 0.6 - 0.7
Vibration per
ISO 22867
Right handle
(Rear grip)
a
hv eq
m/s
2
5.074
Uncertainty K m/s
2
1.5
Left handle
(Front grip)
a
hv eq
m/s
2
3.853
Uncertainty K m/s
2
1.5
Sound pressure level average to ISO 22868
L
PA eq
dB (A) 91.30
Uncertainty K dB (A) 0.85
Sound power level average to ISO 22868
L
WA eq
dB (A) 111.30
Uncertainty K dB (A) 0.85

Makita ER2600L Specifications

General

Blade size	- mm
Blade type	Double blade
Product color	Black, Blue
Fuel tank capacity	0.6 L
Engine displacement	25.7 cm³
Engine power	830 W
Power source	Gasoline

Weight and Dimensions

Depth	1645 mm
Width	220 mm
Height	510 mm
Weight	4300 g
