Makita GD0800C User Manual

2
SPECIFICATIONS
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
GENERAL SAFETY RULES
USA002-2
(For All Tools)
WARNING:
Read and understand all instructions. Failure to follow all
instructions listed below, may result in electric shock, fire and/or
serious personal injury.
SAVE THESE INSTRUCTIONS
Work Area
1.
Keep your work area clean and well lit.
Cluttered benches and dark areas invite acci-
dents.
2.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power
tools create sparks which may ignite the dust
or fumes.
3.
Keep bystanders, children, and visitors
away while operating a power tool. Distrac-
tions can cause you to lose control.
Electrical Safety
4.
Double insulated tools are equipped with
a polarized plug (one blade is wider than
the other.) This plug will fit in a polarized
outlet only one way. If the plug does not fit
fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified elec-
trician to install a polarized outlet. Do not
change the plug in any way. Double insula-
tion eliminates the need for the three wire
grounded power cord and grounded power
supply system.
Model GD0800C GD0810C
Collet size 1/4” 1/4”
Max. wheel point diameter 25 mm (1”) 50 mm (2”)
No load speed (RPM) 7,000 - 28,000/min. 1,800 - 7,000/min.
Overall length 371 mm (14 - 5/8”) 371 mm (14 - 5/8”)
Net weight 1.6 kg (3.5 lbs) 1.7 kg (3.7 lbs)

Makita GD0800C Specifications

General

Maximum diameter of grinding tool	8 mm
Idle speed (max)	28000 RPM
Sound pressure level	78 dB
Sound level uncertainty	3 dB
Vibration level (grinding)	2.5 m/s²
Vibration level uncertainty (grinding)	1.5 m/s²
Input power	750 W
Power source	AC
AC input voltage	110-240 V
Soft start	Yes
Product color	Blue, Grey

Weight and Dimensions

Weight	1600 g
