Makita HM0810T Instructions

4
Symbols
The following show the symbols used for the tool. Be sure that you understand their meaning before use.
❏ Read instruction manual.
❏ DOUBLE INSULATION
❏ Only for EU countries
Do not dispose of electric equipment together with household waste material!
In observance of European Directive 2002/96/EC on waste electrical and electronic equipment and
its implementation in accordance with national law, electric equipment that have reached the end of
their life must be collected separately and returned to an environmentally compatible recycling facil-
ity.

Makita HM0810T Specifications

General

Cord length	5 m
Input power	900 W
Power source	AC
AC input voltage	220 V
Impact rate	2900 bpm
Sound power level	103 dB
Impact energy (max)	7.2 J
Sound pressure level	92 dB
Uncertainty coefficient (concrete)	1.5 m/s²

Weight and Dimensions

Depth	428 mm
Width	96 mm
Height	243 mm
Weight	6000 g
