10 ENGLISH
OPERATION
CAUTION: To connect attachments, such
as nozzle, twist and insert the attachment in
direction of the arrow to secure the connection
during use. To disconnect the attachments, twist
and extract it also in direction of the arrow. If an
attachment is twisted in the opposite direction when
being connected or disconnected, the capsule may
become loose.
1
►1. Capsule
Cleaning (Suction)
Nozzle
Attach the nozzle to clean off tables, desks, furniture,
etc. The nozzle slips on easily.
1
►1. Nozzle
Nozzle + Extension wand (Straight pipe)
Theextensionwandtsinbetweenthenozzleandthe
cleaner itself. This arrangement is convenient for clean-
ingaoorinastandingposition.
1
2 3
►1. Cleaner body 2. Extension wand 3. Nozzle
Corner nozzle
Fit on the corner nozzle for cleaning corners and crev-
ices of a car or furniture.
1 2
►1. Corner nozzle 2. Cleaner body
Corner nozzle +Extension wand
(Straight pipe)
In tight quarters where the cleaner itself cannot
squeeze in, or in high places hard to reach, use this
arrangement.
1 2 3
►1. Corner nozzle 2. Extension wand 3. Cleaner body

Makita HP333D Specifications

General

Drilling	Yes
Chuck type	Keyless
Product design	Pistol grip drill
Number of gears	2
Torque settings	20
Idle speed (max)	1700 RPM
Idle speed (min)	450 RPM
Sound power level	93 dB
Chuck capacity (max)	10 mm
Chuck capacity (min)	0.8 mm
Sound pressure level	82 dB
Sound level uncertainty	3 dB
Drilling diameter in wood (max)	21 mm
Drilling diameter in concrete (max)	8 mm
Vibration level (concrete drilling)	13 m/s²
Vibration level uncertainty (concrete drilling)	1.5 m/s²
Power source	Battery
Battery voltage	12 V
Battery capacity	2 Ah
Product color	Black, Green
Warranty period	3 year(s)

Weight and Dimensions

Depth	193 mm
Width	66 mm
Height	212 mm
Weight	1300 g
