Measuring Functions
11
en
Pythagoras (partial height)
1
5x
2
Aim laser at up-
per point.
3
4
Aim laser at 2nd
point.
5
6
Aim laser at rec-
tangular point.
2.602 m
7
i
• The result is shown in the main line and the measured distance above.
• A reduced level of accuracy, lower than the level of accuracy of the instrument
itself, must generally be expected when the Pythagoras measuring method is
used. In order to obtain the best results we recommend to use a tripod or to flip
out the corner end piece.
• Pressing the measuring key for 2 sec in the function activates automatically
Minimum or Maximum measurement.
Pythagoras
measurements:
