Makita LD080P
13
en
Technical Data
* favourable conditions are: white and diffuse
reflecting target (white painted wall), low background
illumination and moderate temperatures.
** unfavourable conditions are: targets with lower or
higher reflectivity or high background illumination or
temperatures at the upper or lower end of the speci-
fied temperature range.
*** Tolerances apply from 0.05 m to 10 m with a confi-
dence level of 95%.
With favourable conditions the tolerance may deterio-
rate by 0.10 mm/m for distances between 10 m to
30 m and by 0.15 mm/m for distances above 30 m.
With unfavourable conditions the tolerance may dete-
riorate by 0.15 mm/m for distances between 10 m to
30 m and by 0.20 mm/m for distances above 30 m.
For accurate indirect results, the use
of a tripod is recommended. For
accurate tilt measurements a trans-
verse tilt should be avoided.
Distance measurement (ISO 16331-1)
Accuracy with favourable
conditions *
± 1.5 mm / 0.06 in ***
Accuracy with unfavourable
conditions **
± 2.5 mm / 0.10 in ***
Range with favourable
conditions *
80 m / 262 ft
Range with unfavourable
conditions **
60 m / 197 ft
Smallest unit displayed 0.1 mm / 1/32 in
Ø laser point
at distances
6 / 30 / 50 mm
(10 / 50 / 80 m)
General
Laser class 2
Laser type 635 nm, < 1 mW
Protection class IP54 (dust- and splash
water protected)
Autom. laser switch off after 90 s
Autom. power switch-off after 180 s
Battery durability (2 x AAA) up to 5000 measure-
ments
Dimension (H x D x W) 117 x 57 x 32 mm
4.6 x 2.4 x 1.3 in
Weight (with batteries) 0.14 kg / 4.938 oz
Temperature range:
- Storage
- Operation
-25 to 70 °C
-13 to 158 °F
-10 to 50 °C
14 to 122 °F
i
Functions
Distance measuring yes
Min/Max measuring yes
Permanent measuring yes
Stake-out yes
Addition/Subtraction yes
Area yes
Volume yes
Pythagoras 2-point, 3-point,
partial height
Memory 20 displays
Beep yes
Illuminated display yes
Multifunctional endpiece yes
