Makita VC2012L Service Manual

1. EXCHANGE OF COVER
Insert the tip of flathead screwdriver into the
gap between Handle and Cover. Then,
remove the upper part of Handle.
When assembling the Cover, make sure
not to forget to assemble Dedusting rod
in advance.
HANDLE BLACK
COVER
DEDUSTING KNOB
BLACK
CLAMPING
PLATE
DEDUSTING ROD
When removing Filter cleaning, insert the tip of flathead
screwdriver into the gap, and pry it off slowly.
Raise both (right & left) sides of Knob equally, in order to
prevent damage on the resin material of Knob. When
removing Knob, make sure not to let the Compression
spring fall down.
SCREW 5X18
TX20
Remove two Screws of Handle part, and
then remove Handle and Motor head cover.
3

Makita VC2012L Specifications

General

Capacity	- L
Noise level	72 dB
Cable length	7.5 m
Container capacity (dust)	15 L
Container capacity (water)	12 L
Input power	1000 W
Dust class	L
Cleaning type	Dry&wet
Product color	Black, Blue, Silver

Weight and Dimensions

Width	451 mm
Weight	7000 g
