Makita VC2012L Service Manual

4. EXCHANGE OF MOTOR PART
Remove six Screws of Clamping plate.
Then, remove the Clamping plate.
When removing Clamping plate, since it’s connected with
Motor through wires, make sure to support the Motor with
your hands. Be careful not to drop the Motor or disconnect
the wires.
Be careful of disconnection of wire
Exchange parts such as Motor or Upper motor sealing.
CLAMPING
PLATE
SCREW 5X18
TX20
UPPER SEALING
MOTOR
CLAMPING
PLATE
6

Makita VC2012L Specifications

General

Capacity	- L
Noise level	72 dB
Cable length	7.5 m
Container capacity (dust)	15 L
Container capacity (water)	12 L
Input power	1000 W
Dust class	L
Cleaning type	Dry&wet
Product color	Black, Blue, Silver

Weight and Dimensions

Width	451 mm
Weight	7000 g
