Makita VC2012L Service Manual

6. EXCHANGE OF DEDUSTING FLAP
7. EXCHGANGE OF CASTER WHEELS
Use 1R263 and pry the Caster off
In case the shaft is left apart after the
above procedure, use 1R034 as a base (as
shown in left picture) and use 1R263 again
to remove it.
BASE PLATE WITH
AIR OUTLET
DEDUSTING
FLAP
TORSION SPRING
TORSION SPRING
DEDUSTING
FLAP
CONTAINER
CONTAINER
1R263
CASTOR WHEELS
1R034
1R263
Remove Dedusting flap by removing the Torsion spring as
shown in the picture.
8

Makita VC2012L Specifications

General

Capacity	- L
Noise level	72 dB
Cable length	7.5 m
Container capacity (dust)	15 L
Container capacity (water)	12 L
Input power	1000 W
Dust class	L
Cleaning type	Dry&wet
Product color	Black, Blue, Silver

Weight and Dimensions

Width	451 mm
Weight	7000 g
