Makita VC2012L Service Manual

3. EXCHANGE OF SOCKET PART
Remove two Screws located at the inner side of Socket cover.
Next, remove the Screws that are fixing the wires at the back side. Then, exchange Socket.
If you remove the two Screws (located at the inner side of Socket)
before removing the Socket Cover, the PLUG SOCKET FIXING
PLATE (at the back side) will come off as shown in the picture
below. This will make it hard to assemble. So it’s recommended
to do disassembling while the Cover is removed.
SOCKET
SCREW 3,5X18
TX10
PLUG SOCKET
FIXING PLATE
INTERFACE
5

Makita VC2012L Specifications

General

Capacity	- L
Noise level	72 dB
Cable length	7.5 m
Container capacity (dust)	15 L
Container capacity (water)	12 L
Input power	1000 W
Dust class	L
Cleaning type	Dry&wet
Product color	Black, Blue, Silver

Weight and Dimensions

Width	451 mm
Weight	7000 g
