Makita XLC02 - Disposing of Dust for High Performance Filter; Reassembly; Reassembly for Normal Filter

7 ENGLISH
1
2
► 1. Prelter 2. Filter
Disposing of dust for high
performance lter
In order to drop dust sticking on the lter in the capsule,
tap the capsule 4 or 5 times with your hand.
Now point suction inlet downwards, turn capsule in
direction of arrow in diagram, and disconnect capsule
slowly and straight.
1
2
► 1. Capsule 2. Suction inlet
NOTE:
• Dust may spill out when capsule is opened, so
be sure to set a garbage bag beneath capsule.
Remove accumulated dust from inside of capsule and
off of high performance lter.
2
1
► 1. Capsule 2. Hign performance lter
Twist high performance lter in direction of arrow to unfas-
ten securing lip from cleaner unit and then pull off the lter.
1
► 1. Securing lip
Clean out the ne dust and lightly tap to dislodge dust
from high performance lter.
Reassembly
Reassembly for normal lter
Put on lter until it is fully in position on the cleaner unit.
1
► 1. Filter
NOTE:
• Make sure lter is put on straight without being
peeled back. If lter is put on incorrectly as
shown in diagram, dust will get into motor hous-
ing, and cause motor failure.
1
► 1. Filter
Connect prelter. At this time, make sure to twist prel-
ter so that securing lip is rmly locked into cleaner unit.
