2
SPECIFICATIONS
• Manufacturer reserves the right to change specifications without notice.
• Specifications may differ from country to country.
SYMBOLS
END201-2
The following show the symbols used for the
tool. Be sure that you understand their
meaning before use.
...............Read instruction manual.
...............DOUBLE INSULATION
..............Only for EU countries
Do not dispose of electric
equipment together with
household waste material!
In observance of European
Directive 2002/96/EC on
waste electric and electronic
equipment and its implemen-
tation in accordance with
national law, electric equip-
ment that have reached the
end of their life must be col-
lected separately and
returned to an environmen-
tally compatible recycling
facility.
Intended use
The tool is intended for impact drilling in
brick, concrete and stone as well as for drill-
ing without impact in wood, metal, ceramic
and plastic.
Power supply
The tool should be connected only to a
power supply of the same voltage as indi-
cated on the nameplate, and can only be
operated on single-phase AC supply. They
are double-insulated in accordance with
European Standard and can, therefore, also
be used from sockets without earth wire.
For Model MT810/MT811/MT812
For European countries only
Noise and Vibration
The typical A-weighted noise levels are
sound pressure level: 95 dB (A)
sound power level: 106 dB (A)
Uncertainty: 3 dB
– Wear ear protection. –
The typical weighted root mean square
acceleration value is 10 m/s
2
.
These values have been obtained according
to EN60745.
Model MT810 MT811/MT812 MT813
Capacities
Concrete 10 mm 13 mm 16 mm
Wood 18 mm 18 mm 30 mm
Steel 10 mm 13 mm 13 mm
No load speed (Min
-1
)
0 - 2,800 0 - 2,800 0 - 3,000
Blows per minute 0 - 30,800 0 - 30,800 0 - 45,000
Overall length 258 mm 272 mm 297 mm
Net weight 1.4 kg 1.6 kg 2.0 kg
Safety class
/II
