SEQUENCE LENGTH, RESET/HOLD, DIVIDE,
ATTENUATION AND OFFSET IN CV MODE
MALEKKOHEAVYINDUSTRY.COM
You can adjust the LENGTH of a
sequence (amount of steps per
sequence) by selecting LENGTH
and then the button corresponding
to the last step in the sequence.
For instance, if you only want an 8
step sequence, simply select the
8th STEP button.
RESET/HOLD:
In CLOCK and SLAVE mode, a
gate inserted into RST/HOLD will
cause the Voltage Block to reset
to step 1 (when the gate is high).
If the interpolation mode is set to
CV instead of CLOCK or SLAVE,
RST/HOLD will hold the current
step while the gate is high.
DIVIDE the length of your
sequence by 16 while in
CLOCK or SLAVE mode.
ATTENUATE will attenuate the
incoming CV, in turn the amount
the Voltage Block sequences
will respond to this signal.
OFFSET will change the
starting step of a sequence
when in CV interpolation mode.
PG. 9
VOLTAGE BLOCK MANUAL V.1
