MALEKKOHEAVYINDUSTRY.COM
PG. 11
VOLTAGE BLOCK MANUAL V.1
The following scales are
available starting on STEP
button 1:
1: Unquantized
2. Japanese
3. Major Pentatonic
4. Minor Pentatonic
5. Blues
6. Locrian
7. Arabian
8. Phrygian
9. Minor
10. Dorian
11. Mixolydian
12. Persian
13. Double Harmonic
14. Major
15. Lydian
16. Chromatic
To Freeze the last voltages played
on individual channel outputs,
select the SHIFT button and then
hold the FREEZE button while you
select an output. LEDs will turn on
for those frozen channels. When
paired with Varigate 8+, V8+
FREEZE messages will also freeze
the Voltage Block corresponding
voltages/channels.
Arpeggiator Mode:
In CLOCK or SLAVE mode,
whenever more than 2 buttons are
pressed they will be clocked
through in the order they are
pressed. When no clock is
present, pressing a button will
manually select the last step
pressed.
FREEZE, ARP AND AVAILABLE SCALES
