Chapter 2 Hardware features
Page 2-6 MAN 0385
threshold settings may need adjusting. The Essentials Manual has more details
on cleaning the level sensor.
The level sensor must be set to detect different types of dispersant by setting the
level sensor threshold. This is done by selecting Configure-Accessories. The
Level Sensor Threshold section is shown below:
Use the up and down arrows to set the threshold for the dispersant used then click
the Apply button. The values of commonly used dispersants are listed below:
The level sensor threshold must always be set when a different dispersant is used.
Level sensor thresholds are also stored in the dispersant database.
Tank cover
The tank cover is there to protect the operator from splashes from the tank. Always
replace the cover after adding sample to the tank.
Water (default) 64%
White spirit 36%
Propan-2-ol 64%
2-2-4 Trimethyl pentane 36%
MAN0385-1.0 Hydro 2000G-S.book Page 6 Friday, March 16, 2007 4:02 PM
