Chapter 2 Hardware features
Page 2-14 MAN 0385
Use the up and down arrows to set the threshold for the dispersant then click the
Apply button. The values of some commonly used dispersants are listed below.
Water (default) - 64%
White spirit - 36%
Propan-2-ol - 64%
2-2-4 Trimethyl pentane - 36%
The level sensor threshold must always be set when a different dispersant is used.
Level sensor thresholds are also stored in the dispersant database.
Rear panel
This illustration identifies the main features of the rear panel:
ill 4917
Drain and overflow
The drain and overflow port is the exit point where sample/dispersant leaves the
dispersion unit. A warning triangle warns that the contents of the tank are drained
10
4
5
3
2 9 87
6
1
MAN0385-1.0 Hydro 2000G-S.book Page 14 Friday, March 16, 2007 4:02 PM
