8
TEMPERATURE CONTROL
When your fridge/freezer is rst connected to the AC or DC power input
the appliance will automatically switch on and the LCD control panel will
display the current cabinet temperature, battery monitor and Eco setting
as well as the current input voltage.
The Temperature Controller provides the ability to set the desired
temperature level and display the current cabinet temperature. The
electronic controller has been programmed to maintain an average
of the set temperature.
The compressor will start up when the internal cabinet temperature
increases 0.5 to 1.5 degrees above the set temperature and will run
until the temperature is 0.5 to 1.5 degrees below the set temperature.
BATTERY DISPLAY
Voltage is measured at the input connection on the side of the appliance.
*Values are for reference only and may be subject to change depending on conditions
and power supply.
Battery Display
12V 24V
0 BAR 11.0V or less 22.0V or less
1 BAR 11.0V to 11.5V 22.0V to 23.0V
2 BAR 11.5V to 12.0V 23.0V to 24.0V
3 BAR 12.0V to 12.5V 24.0V to 25.0V
4 BAR 12.5V or above 25.0V or above
