Technical data
64
Model D 2842 LE 404/407/410/414/415/416/417
Design V 90°
Cycle 4-stroke Diesel with turbocharging /
intercooling and wastegate
Combustion system Direct injection
Turbocharging Turbocharger with intercooling
and wastegate
Number of cylinders 12
Bore 128 mm
Stroke 142 mm
Swept volume 21 930 cm
3
Compression ratio 13.5 : 1
Rating see engine nameplate
Firing order 1-12-5-8-3-10-6-7-2-11-4-9
Valve clearance (cold engine)
Intake 0.50 mm
Exhaust 0.60 mm
Valve timing
Intake opens 24° before TDC
Intake closes 36° after BDC
Exhaust opens 63° before BDC
Exhaust closes 27° after TDC
Fuel system
Injection In-line pump
Governor Electronic Diesel Control
(EDC) - Model M(S) 5
Start of delivery
D 2842 LE 404
up to engine No. ... 9029 045 ....
from engine No. ... 9029 046 ....
23°±1° before TDC
21°±1° before TDC
D 2842 LE 410 / 415 19°±0,5° before OT
D 2842 LE 407 / 414 / 416 / 417 20°±0,5° before OT
Injectors five-hole nozzles
Opening pressure of injector
New nozzle holder 290+8 bar
Used nozzle holder 280+8 bar
