Technical data
60
Model D 2842 LE 401 / 402 / 403 / 406 / 408
D 2842 LE 411 / 412 / 413
Design V 90°
Cycle 4-stroke Diesel with turbocharging /
intercooling and wastegate
Combustion system Direct injection
Turbocharging Turbocharger with intercooling
and wastegate
Number of cylinders 12
Bore 128 mm
Stroke 142 mm
Swept volume 21 930 cm
3
Compression ratio 13.5 : 1
Rating see engine nameplate
Firing order 1−12−5−8−3−10−6−7−2−11 −4−9
Valve clearance (cold engine)
Intake 0.25 mm
Exhaust 0.40 mm
Valve clearance changed from engine No. ... 7651 046 ....
Intake 0.50 mm
Exhaust 0.60 mm
See instruction label on valve cover
Valve timing
Intake opens 24° before TDC
Intake closes 36° after BDC
Exhaust opens 63° before BDC
Exhaust closes 27° after TDC
Fuel system
Injection In-line pump, V-saddle-mounted
Governor Centrifugal governor (variable-range
speed governor) with smoke stop
