Engine type Exhaust gas flow Exhaust gas temp.
DN
Nominal diameter
Exhaust gas
velocity
kg/h °C mm m/sec.
5L28/32DF, 720/750 rpm
6L28/32DF, 720/750 rpm
7L28/32DF, 720/750 rpm
8L28/32DF, 720/750 rpm
9L 28/32DF, 720/750 rpm
8800
10500
12300
14100
15800
342
342
342
342
342
450
450
500
550
550
28.8
34.5
32.6
30.9
34.6
5L16/24, 1000 rpm (90 kW)
6L 16/24, 1000 rpm (95 kW)
7L16/24, 1000 rpm (95 kW)
8L16/24, 1000 rpm (95 kW)
9L16/24, 1000 rpm (95 kW)
3100
3900
4500
5200
5800
375
375
375
375
375
300
300
300
400
400
21.1
26.9
31.1
22.6
25.4
5L16/24, 1200 rpm (100 kW)
6L16/24, 1200 rpm (110 kW)
7L16/24, 1200 rpm (110 kW)
8L16/24, 1200 rpm (110 kW)
9L16/24, 1200 rpm (110 kW)
3600
4700
5500
6300
7100
356
356
356
356
356
300
300
400
400
400
23.8
31.4
23.2
26.6
29.9
5L27/38, 720 rpm (300 kW)
6L27/38, 720 rpm (330 kW)
7L27/38, 720 rpm (330 kW)
8L27/38, 720 rpm (330 kW)
9L27/38, 720 rpm (330 kW)
10300
13600
15900
18100
20400
376
376
376
376
376
500
550
600
600
650
28.8
31.4
30.6
35.0
31.8
5L27/38, 750 rpm (320 kW)
6L27/38, 750 rpm (330 kW)
7L27/38, 750 rpm (330 kW)
8L27/38, 750 rpm (330 kW)
9L27/38, 750 rpm (330 kW)
11200
13900
16200
18500
20800
365
365
365
365
365
500
550
600
600
650
30.8
31.6
30.7
35.1
31.9
Density of exhaust gasses ρ
A
~ 0.6 kg/m
3
MAN Diesel & Turbo
B 16 01 0
Exhaust gas velocity
3700152-6.2
Page 2 (4)
L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, L16/24, L21/31,
L23/30H, L27/38, L28/32H
2015.11.09 - Tier II, Stationary
