Dismantling space
It must be taken into consideration that there is suf-
ficient space for pulling the charge air cooler ele-
ment, lubricating oil cooler, lubricating oil filter car-
tridge, lubricating pump and water pumps.
Figure 2: Overhaul areas for charge air cooler element, lub. oil cooler and lub. oil filter cartridge.
MAN Diesel & Turbo
B 10 01 1
Overhaul areas
1665770-6.6
Page 4 (4)
L27/38S, L27/38
2015.11.27
