Accessibility of engine in engine room
15
D Draining the coolant É and
11
(Description in the Operating Instructions)
D Maintenance of the plate−core heat exchanger
D Replacing belts
12
D Replacing starter, alternator
13
And coolant
pump
D Visual inspection and retightening of bolts and
hose connections
Distance to bulkhead: D=350 mm
Removing the cylinder head cover
14
to
D Adjustment of valve clearance
16
D Replacement of the injectors
15
Loosening and removal of the cylinder head
bolts
17
Danger:
The red emergency stop button on the
terminal box must be quickly and easily
accessible!
10
11
12
13
16
17
14
15
