Transmission of power by propshafts
32
Drive line consisting of engine, highly resilient coupling, propeller shaft and
gearbox
1
2
3
4
5
Drive line consisting of engine, resilient coupling with flange bearing, propeller
shaft and gearbox
2
5
4
3
1
