MMDS CAN bus
84
1 Terminating resistor 51.25435−0174
2 T-piece 51.25433−0023
3 Adapter piece 51.25411−6014
4 VDO CAN-Master tachometer with display for
engine parameters
51.27102−7003
5 VDO CAN-Slave display e.g. engine oil pressure,
engine oil temp., coolant temp., exhaust gas
temp., ...
6 Connectors to other CAN slave displays, like
engine oil temp., coolant temp., exhaust temp.,
etc.
7 Throttle lever for control stand 1 51.11605−6055
8 Throttle lever for control stand 2 51.11605−6055
9 Throttle lever line 51.25449−0052 (10 m); 51.25449−0053 (15 m)
51.25449−0054 (20 m); 51.25449−0055 (30 m)
10 Terminal box
11 Connecting line to override button (X16) 51.25449−0047 (15m); 51.25449−0048 (20m);
51.25449−0058 (30m)
12 X9
13 Cross communication MMDS (X5) 51.25449−6040 (2 m); 51.25449−6028 (5 m);
51.25449−6027 (10 m)
14 Cross communication MPC − CAN−bus (X13) 51.25449−0056 (2 m); 51.25449−0057 (5 m);
51.25449−0057 (10 m); 51.25449−0057 (15 m);
15 Gearbox controller line, trolling (X8)
16 Diagnosis connection MAN−Cats, diagnosis
software MMDS, reprogramming EDC7 (X10)
17 Start−Stop panel (EOP), (X7)
18 Ground connection
19 Shipyard connector with cable (X4)
20 Engine wiring harness (X1)
21 Remote control
22 Connecting line to remote control of
CLC display
23 Display CLC 6.5
24 Connecting cable with 7 open wires to connect
power supply, horn, summary alarm, horn (2 m)
No part number, fixed connection
25 CAN connecting line (X6) 51.25411−0025 (2 m); 51.25411−0026 (10 m);
51.25411−0015 (15 m) 51.25411−0016 (20 m);
51.25411−0027 (25 m)
26 Emergency unit
