Crane transport of the engine
25
Transporting drive line onto ship
Caution:
When working on the engine make sure to
not step on the engine cover À.
Use crane lifting equipment to lift engine.
Danger:
Using unsuitable lifting equipment that is
not strong enough for the load may result
in serious accidents/injury!
Make sure ropes and chains do not pull
crookedly on the crane hooks.
There are 4 crane hook lugs Á on the engine to be
used when lifting the engine without the gearbox
attached.
When lifting the engine with the gearbox attached,
use the engine’s two front crane hook lugs and the
other two on the gearbox Â.
1
2
3
