27- PROPORTIONAL CONTROL HANDLE FOR TRANSLATION FUNCTION
- Move the control lever in the direction indicated by the white arrow on the control panel to
advance the machine in the direction indicated by the arrow. Move the control lever in the
direction indicated by the black arrow on the control panel to advance the machine in the
direction indicated by the arrow.
28- STEERING FUNCTION THUMB SWITCH
- Press the left side of the thumb switch to steer the machine left.
- Press the right side of the thumb switch to steer the machine right.
29- WRIST REST
- This helps you to grasp the joystick.
30- LIFTING CONFIRMATION BUTTON, WITH INDICATOR
- Press this button to activate the lifting function.
- NB: The translation and steering functions are not available from the ground controls.
