Manitou Circus Expert - Casting Removal & Service; Remove Rebound Knob; Disengage Rebound Damper Rod; Remove Compression Rod Bolt

10
CIRCUS EXPERT SERVICE MANUAL
CASTING REMOVAL & SERVICE
1
Remove rebound knob using a
2mm hex wrench.
Insert an 8mm hex wrench into the
end of the rebound damper rod and
turn the rod clockwise until it is
disengaged from the casting and
can be pushed into the casting.
2
3
Use a 12mm wrench to remove the
compression rod bolt.
