19
CIRCUS EXPERT SERVICE MANUAL
DAMPER SERVICE
6
7
Remove rebound damper assembly
from the fork. Once the damper
assembly is removed, clean the inside of
the stanchion with isopropyl alcohol and
a lint free towel. Inspect the inside and
outside of the stanchion for scratches
and other damage. Inspect rebound
damper for damage as well. Replace if
necessary.
Install rebound damper into stanchion.
Using a 22mm crow’s foot and torque
wrench, tighten the rebound damper
assembly end cap to 80-100 in lbs [9.0-
11.3 NM].
