Manitou MSI 20 D User Manual

2 - 7
By water
Sucking (up to machine n° 130839)
Blowing (from machine n° 130840)
6
406,4 mm
80/84 °C
96 °C
Negative
12 V - 105 Ah - 680 A EN
14 V - 55 A
Incorporated into the alternator.
12 V - 2,2 kw
A4VG90DA With variable cubic capacity and
with automatic power governor.
Electromagnetic 12V.
90 cm
3
0 cm
3
215 L/mn
500 Bar
18,7 cm
3
42 L/mn
30 Bar (Transmission in neutral).
A2FE With fixed capacity.
28 cm
3
CWD 2050/M BREVINI
Multidisc brake immersed in oil.
4
4
Foot pedal. Hydraulic brake acting on front
wheels through pressure break.
Switch. Electro-hydraulic brake acting on front
wheels through pressure break.
COOLING CIRCUIT
- Type
- Fan
. Number of blades
. Diameter
- Thermostat
. Start opening
. Full opening
ELECTRIC CIRCUIT
- Earth
- Battery
- Alternator
- Tension regulator
- Starter
HYDROSTATIC TRANSMISSION
HYDROSTATIC PUMP
- Type
- Gear reverser
- Main pump
. MAX. displacement
. MINI. displacement
. MAX. flow rate
. Working pressure
- Boost pump
. Cubic capacity
. MAX. flow rate
. Boost pressure MAX. r.p.m.
HYDROSTATIC WHEEL ENGINE
- Type
. Cubic capacity
FRONT WHEEL REDUCERS
- Type
BRAKE
- Type
- Number of steel disks
- Number of friction disks
- Service brakes
- Parking brakes

Manitou MSI 20 D Specifications

General

Brand	Manitou
Model	MSI 20 D
Category	Forklifts
Language	English
