3-38
H - RULES FOR PERIODIC INSPECTION OF THE MAIN SAFETY FUNCTIONS
If the results of the above checks are negative, please contact your dealer.
- This non-exhaustive requirement is intended as an aid and does not affect the list of inspections of the approved body.
ON THE LIFT TRUCK
1 - LONGITUDINAL STABILITY ALARM
- Take a load of known mass greater than 1000 kg.
- Park the lift truck on ground that is level and free of obstructions.
- Remain on tyres and set the jib horizontally.
- Gradually telescope the jib and check that the longitudinal stability and hydraulic movement cut-off data match the indications
shown on the load chart (see: 2 - DESCRIPTION: 7 - LONGITUDINAL STABILITY ALARM DEVICE).
2 - EMERGENCY STOP BUTTON IN THE CAB
- Place the lift truck on level ground with the I.C. engine idling.
- Push the Emergency stop button, the IC engine must stop.
- A visual alarm
and a long sound signal are triggered at the same time, and the general fault screen
!
appears on the screen display.
3 - GROUND STABILISERS
- Place the lift truck on level ground with the I.C. engine idling.
- Lower the stabilisers to raise the front of the lift truck.
- The symbol indicating that the stabilisers are down and under pressure
should appear on the operating screen
.
4 - PARKING BRAKE
- Place the lift truck with its rated load on a slope of 15 % (8,5°) or slightly greater with the I.C. engine idling.
- Stop the I.C. engine and check that the lift truck does not move.
5 - DRIVER PRESENCE
- Validate the driver’s presence (see: 2 - DESCRIPTION: 6A - DRIVER PRESENCE).
- Place the lift truck on level ground with the I.C. engine idling.
- Check that the lift truck (FORWARD/NEUTRAL/REVERSE) movement and the jib hydraulic movement functions are available.
- Release the accelerator pedal and open the door.
- Jib hydraulic movement and lift truck movement must be disabled.
