Manitou MT 1840 R PRIVILEGE User Manual

2-11
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (jib retracted)
Unladen lifting s - m/mn 16,1 - 24,5
Laden lifting s - m/mn 16,2 - 24,4
Unladen lowering s - m/mn 12,3 - 32,1
Laden lowering s - m/mn 12 - 32,9
Telescoping motions (jib raised)
Unladen extending s - m/mn 27,5 - 20,4
Laden extending s - m/mn 33 - 24,4
Unladen retracting s - m/mn 26,4 - 25,5
Laden retracting s - m/mn 25,7 - 26,2
Tilting movements
Unladen digging s - °/s 4,3 - 29,3
Forward tilting unladen s - °/s 4 - 31,5
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground
(except particular conditions)
Front unladen 1 km/h 5,1
2 km/h 8,1
3 km/h 15,2
4 km/h 25,7
Rear unladen 1 km/h 5,1
2 km/h 8,1
3 km/h 15,2
4 km/h 25,7
Standard attachment TFF 45 MT1040
Weight with forks kg 224
Weight of forks (each one) kg 73
Rated capacity with standard attachment kg 4000
Tipping load at maximum reach on stabilisers kg 950
Distance from the centre of gravity from the load to the lug of the forks mm 500
Standard lifting height mm 17500
Lift truck weight without attachment kg 11010
Lift truck weight with standard attachment
Unladen kg 11380
At rated load kg 15380
Weight per axle with standard attachment (transport position)
Front unladen kg 5260
Rear unladen kg 6120
Front rated load kg 12850
Rear rated load kg 2530
Weight per axle with standard attachment (jib extended)
Front rated load kg 10990
Rear rated load kg 490
Contact pressure on the ground for the whole surface of each stabilizer
at maximum load when tilting
kg/cm2 5,6
Drag strain on the coupling hook
Unladen (sliding) daN 8400
At rated load (transmission setting) daN 10300
Pull strain with open carrier
(according to standard ISO 8313) daN
HYDRAULIC CIRCUIT
Hydraulic pump
Type Gear pump with flow divider on 2nd casing
1st casing 2nd casing
Capacity cm3 45 27
Max. rating capacity unladen l/mn 106 64
Flow rate at 1600 rpm l/mn 72 44
Filtration
Return μm 16 16
Suction μm 135 135
Maximum service pressure bar 270
Telescoping circuit bar 180 / 270
Lifting circuit bar 210 / 270
Tilt circuit bar 280 / 200
Stabilizers Circuit bar 270
Tilting corrector circuit bar 270
Attachment circuit bar 270
Steering circuit bar 140
